Master Advanced PLC Programming & IIoT for Industrial Automation

This comprehensive PLC programming course empowers you to excel in industrial automation and leverage the Industrial Internet of Things (IIoT).  Equip yourself with the knowledge and skills to program PLCs and unlock the power of IIoT for efficient industrial processes.

Deep Dive into PLC Programming (IEC61131) for Industrial Applications

PLCs (Programmable Logic Controllers) are vital for industrial automation, controlling and monitoring complex processes. This advanced course dives deep into PLC programming, specifically focusing on the industry-standard IEC61131.

Master Diverse PLC Programming Languages

Our experienced instructors will equip you with the expertise to program using various IEC61131 languages, including ladder diagram (LD), structured text (ST), and function block diagram (FBD).  Learn to design, implement, and troubleshoot PLC programs for diverse industrial applications, ensuring reliable and efficient automation.

Objectives:

Upon completing the Advance PLC Programming with IIOT course from IIPD, the candidate should be able to perform the following functions at site,

• Locating and identifying the hardware system
• Creating a new program
• Interpret and understand IEC61131-based programming
• Programming Sub Routines
• Creating FB’s & FC’s
• Configuring Remote IO Modules
• Troubleshooting I/O Faults
• Troubleshooting Communication issues
• Adding an IIOT Gateway to the system
• Configuring IIOT Gateway for Data Collection
• Remote data Logging, Alarm generation & MQTT Configuration

PLC Available Brands:

• Siemens
• Allen Bradley
• Schneider
• Mitsubishi
• Delta

IIoT Gateway: Ewon Flexy

PLC Outline:

• Design of the System and Components
• Software Packages and Versions
• Controller Properties
• Selection of Controllers
• Communication Configuration & IP Settings
• Network Topology
• Different communication mediums
• Interfacing with Peripherals
• Remote IO configuration
• Profibus / Profinet device configuration
• Communicating to VFD via Profibus, Profinet, and Modbus 485
• Data reading from MFM’s through Modbus

IIOT Outline:

• Data Collection from PLC
• Data Logging – Historical & Real-time
• Alarm Generation
• Sending data to the Cloud through MQTT

Pre-Requisite:

• Understanding of Electrical Systems
• Knowledge about Automation Systems
• Engr/Technician Level candidates

Methodology:

• One to One – Hands-on session
• On-Line Sessions(Batch)
